304 Stainless Steel Speed Gate with Servo Motor and Face Recognition

Name: 304 Stainless Steel Speed Gate with Servo Motor and Face Recognition
Brand: DOOR or OEM
Price: 1 USD

Buy cheap 304 Stainless Steel Speed Gate with Servo Motor and Face Recognition product

Brand Name : DOOR or OEM

Model Number : DR.TD6623

Certification : CE / IS09001

Place of Origin : China

MOQ : 1 lane

Price : Negotiable

Payment Terms : T/T

Supply Ability : 2500 sets per month

Delivery Time : 5-7 working days

Packaging Details : wood carton

Material : 304# Stainless Steel

Suitable For : Access Control, Entrance And Exit Control

Turnstile Material : SUS304 Stainless

Communication Interface : RS485,dry Contact

Power Supply : AC110/AC220+/-10%

Swing arm available : Acrylics Or Tempered Glass

Driving Motor : Servo Motor

Opening Signal Input : Dry Contact

Working environment : -25℃-+70℃

Pass speed : 30-50p/m

Support System : Face Recognition,ic/id Card,fingerprint

Motor : Servo motor

IR Sensor : 8 pairs

Passage Width : Standard 600mm, max 900mm

IP Rating : IP42

Mean Cycles Between Failure : 20 million times

Voltage : AC110V/AC220V±10% 50-60Hz

Operating Power : Single Core 100w, dual core 200w

Method of position : Motor + clutch + encoder

Mtbf : 10 Million Times

Size : L1600×W160×H1030mm

Weight : 80kg

Color : Silver

Contact Now

IP42 Speed Gate 6623 With Servo Motor And Encoder Positioning Made In China Well-Know Brand

Product Specifications

Key Features

8-pair infrared anti-pinch protection with fire alarm linkage
Triple pedestrian protection system: infrared sensors, pass logic, and return-when-blocked
Multiple operation modes: normally closed (locking/non-locking) and peak traffic
Memory opening, delay closing, and overtime closing functions
Bidirectional traffic capability with ≤180° swing arc
Integrated card/QR code reader with face recognition compatibility
Fire-safe free passage during power outages
Ultra-fast 0.5 second opening/closing speed
Servo motor driven for reliable, quiet operation with extended lifespan

304 Stainless Steel Speed Gate with Servo Motor and Face Recognition

Applications

Widely used for official or corporate buildings, sectioning off certain areas in hotels (gyms, spas), industrial buildings or offices.

Customization Options

Customized logo (Min. order: 2 pieces)
Customized packaging (Min. order: 2 pieces)
Graphic customization (Min. order: 2 pieces)

Supplier's Customization Ability

Minor customization
Drawing-based customization
Sample-based customization
Full customization

304 Stainless Steel Speed Gate with Servo Motor and Face Recognition

Packing Information

Plywood case size: 167*35*114cm
G.W.: 85KG

Shipping Information

Shipping fee and delivery date to be negotiated. Contact supplier for more details.
